CS / SS LIFT CHECK VALVE - BW / FL | Lift Check Valves (NRV) Manufacturer | Caliber Valves

Compliance: BS 1873 / API 600 / API 602 / ASME B16.34 / ASME B16.10 / API 598 / ISO 12266-1

Size Range: 25 to 200 DN

Pressure Rating: 150#

Lift Check Valves (NRV)

CS / SS LIFT CHECK VALVE - BW / FL

Cast Steel / Stainless Steel Lift Check Valve with piston lift up mechanism and guided disc for horizontal mounting.

Key Specifications
Size25 to 200 DN
PressureUp to 22 Kg/cm2
Rating150#
TemperatureUp to 427°C
MaterialWCB / CF8 / CF8M
StandardsBS 1873 / API 600 / API 602 / ASME B16.34 / ASME B16.10 / API 598 / ISO 12266-1
ComplianceBS 1873 / API 600 / API 602 / ASME B16.34 / ASME B16.10 / API 598 / ISO 12266-1
Size Range25 to 200 DN
Design FeaturesPiston Lift Up, Guided Disc, Spring Loaded, Horizontal Mounting
Rating150#
End ConnectionsBW / Flanged 150#
PressureUp to 22 Kg/cm2
TemperatureUp to 427°C
